• Suitable for wall or window installation.

• For intermittent extract of shower rooms, en suites, w.c's.

• Not suitable for ducting up to roof tile vents.

• Not suitable for flat ducting.

• IPX4 splash proof protection on all models. If installing in ceiling need additional gasket to maintain IPX4 protection.

• Automatic Shutter models can be window fitted by use of the Punto Window Kit.

• The standard models can be speed regulated.

• Timer models are adjustable from 3 to 20 minutes.

• HCS Models have an adjustable humidistat that turns the fan on when relative humidity exceeds the selected setting.

• High airflow rate, low operating noise level and low power consumption due to the wing profile blade and motor support.

• Available option of automatic shutters, timer, pull cord, humidistat, and PIR.

Specification

V ~ 50 Hz: 230-240

W: 18

A: .01

Rpm: 2300

Delivery m3/h: 90

Delivery l/s: 25

Lp dB(A) 3 m: 37.5

IP Rating: IPX4
