Schneider Square D IKQ 12 Way 125A SP+N Type A Metalclad Distribution Board
Model:SE125A12
Schneider Square D IKQ 12 Way 125A SP+N Type A Metalclad Distribution Board
Model:SE125A12
-
£81.90 Inc VAT ( FREE UK Delivery On Orders Over £150* )
£68.25 Ex VAT ( FREE UK Delivery On Orders Over £150* )
Product: In Stock
Key Features
- Maximum
busbar rating 125A
- Shielded
neutral bars
- Cable
knockouts on all sides for speed of installation
- Earth
bar capacity 25mm²
- Neutral
bar capacity 25mm²
- Accept DIN control products contactors, time clocks, in any unused outgoing way without adaptation
Comes with 125 Amp incomer, Smart process smart rail x100-mid, and a SE125L2 termial block 2p 125A
Specification
| Brand | Schneider Square D |
| Current Rating | 125A |
| Depth | 127mm |
| Dimensions | (H)270 mm x (W)376 mm x (D)127 mm |
| Guarantee | 1 Year |
| Height | 270mm |
| Number of Outgoing Ways | 12 |
| Packaging Types | Each |
| Standards | BS EN 61439 |
| Type | A |
| Unspsc | 39121110 |
| Voltage Rating | 230V |
| Weight | 4.77000kg |
| Width | 376mm |
