ABB System Pro M Compact S200 MCB, 3P Poles, 100A Curve B
Model:S203B100
ABB System Pro M Compact S200 MCB, 3P Poles, 100A Curve B
Model:S203B100
-
£68.99 Inc VAT ( FREE UK Delivery On Orders Over £150* )
£57.49 Ex VAT ( FREE UK Delivery On Orders Over £150* )
S203-B100 Miniature Circuit Breaker B-Char. 6kA, 100A, 3P
·
Miniature Circuit Breaker
·
Number of Poles 3
·
Rated Current (In) 100 A
·
Standards IEC/EN 60898-1IEC/EN 60947-2
·
Rated Frequency (f) 50/60 Hz
Technical
Miniature
circuit breaker (MCB) |
|
·
Rated
voltage |
400 V |
·
Additional
equipment possible |
Yes |
·
Concurrently
switching N-neutral |
No |
·
Frequency |
50 - 60 Hz |
·
Ambient
temperature during operating |
-25 - 55 °C |
·
Connectable
conductor cross section multi-wired |
4 - 35 mm² |
·
Connectable
conductor cross section solid-core |
2.5 - 50 mm² |
·
Rated
short-circuit breaking capacity Icn EN 60898 at 230 V |
kA |
·
Number
of protected poles |
3 |
·
Width
in number of modular spacings |
3 |
·
Current
limiting class |
3 |
·
Rated
insulation voltage Ui |
440 V |
·
Voltage
type |
AC |
·
Rated
impulse withstand voltage Uimp |
kV |
·
Rated
short-circuit breaking capacity Icu IEC 60947-2 at 230 V |
kA |
·
Rated
short-circuit breaking capacity Icu IEC 60947-2 at 400 V |
6 kA |
·
Rated
short-circuit breaking capacity Icn EN 60898 at 400 V |
6 kA |
·
Number
of poles (total) |
3 |
·
Over
voltage category |
3 |
·
Rated
current |
100 A |
·
Built-in
depth |
69 mm |
·
Pollution
degree |
3 |
·
Degree
of protection (IP) |
IP20 |
·
Release
characteristic |
B |
